EP, AP & THP SERIES

EP Series Features:

1.  High Output 2Stage Pumps

2.  Advanced Circuit Technology
Fewer components and wiring reduce weight & increases dependability

3.  Powerful, Efficient, Compact

4.  Lightweight Motor
Permanent Magnet Motor is available in 1.125 HPand 1.5 HPversions

5.  Operates At Full Pressure
On a 20 amp @115 VAC circuit, makes the pump ideal to use with an extension cord

6.  Low Profile Design Simplifies Transport
Site gauge enables operator to monitor reservoir oil levels. Powder coated reservoirs stand up to the harshest environments. "Easy-Pour" fill and drain hole makes preventative maintenance quick and easy.

7.  Enhanced Reservoirs
Available in 1 and 1.5 Gallons

8.  Quadra-Torc Function
Available in single and multi-port designs for running multiple tools simultaneously

9.  Lightweight, Ergonomic Pendant
Industrial ergonomic rocker switches easy to activate, reducing hand fatigue. Water resistant sealed switches operate on 12 VCD

10.  Roll Cage & Heat Exchangers Available

11.  Auto-Dump
Relieves all pressure from hoses

12.  Replaceable MotorBrushes & Armature
Increases serviceability

13.  10’Pendant Standard
On all Torque Powerpump models

AP Series Features:

1.  High Output 2Stage Pumps

2.  Heavy Duty Air Motor
Powerful 4 HPindustrial duty air motor runs on 50cfm/100 PSI

3.  Quadra-Torc Function (Optional)
Available in single and multi-port designs for running multiple tools simultaneously

4.  Quiet Operation
Approximately 80dB @ 10,000 PSI

5.  Rugged Remote
10’remotependanttocontrolmotor and valve

6. Auto-Dump
Relieves all pressure from hoses

7.  Filter-Lubricator
Supplied with high flow F/R/Lfor long trouble free operation

8.  1.5 Gallon Reservoir

9.  Precise PSI/BAR 4" Pressure Gauge

10. Quick Connect Couplers
Each pump and hose is fitted with quick connect, no-drip, thread-less safety couplers, with 2:1 safety ratio

11.  Supplied with dual non-conductive
High pressure hose with couplers

12.  Standard carrying handle provided
Optional roll cage available to protect motor

13.  Low Centre of Gravity
For more stability

14.  ForUse In Flammable Environments

15.  Serviceable MotorVanes & Springs

THP 101 Series Features:

1.  Full Automatic PowerPack

2.  Powerful, Efficient, Compact, Faster

3.  Reliability
High reliability of bolting process without pressing the button again and again

4.  Heavy Duty Motor
Power rating 1.5HPat 800bar

5.  High pressure Thermoplast Twin Hoses

6. Mounted with working hours counter

7.  Noiseless & vibration free operation
(Motor / Pump immersed with oil)

8.  Safety
Power Pack Switches off automatically if temperature rises above 80° C

9.  Oil Cooler
Inbuilt heat exchanger to cool the system

10. PLC controlled system
Effectively controlled operations of powerpack

11.  Rugged Remote
Remote pendant to control motor / pump

12.  Enhanced reservoir
Available in 8 Lt

13.  Flow Rate
Available at 9.7LPM @ 100 bar, at 0.97LPM @ 700 bar

14.  ForUse In Flammable Environments

15.  Power Rating : 1.5HP

15.  Capacity : 8 Lt
